oracle 11g rac 添加新节点及故障解决案例
系统环境：
操作系统：RedHat EL55
集群： Oracle 11g GI
Oracle： Oracle 11gR2
一、配置新的节点
1.首先按照其他节点进行 系统基本参数配置
2.添加hosts到所有节点 并完成用户等效性配置 (grid,oracle)2个用户
二、添加GRID节点
以grid用户登录
静默方式 完成grid节点添加
# su – grid
[grid@node1 ]$ cd $ORACLE_HOME/oui/bin
[grid@node1 bin]$ ./addNode.sh “CLUSTER_NEW_NODES={node3}” “CLUSTER_NEW_VIRTUAL_HOSTNAMES={node3-vip}”
Starting Oracle Universal Installer…
Checking swap space: must be greater than 500 MB. Actual 5951 MB Passed
Checking monitor: must be configured to display at least 256 colors. Actual 256 Passed
Oracle Universal Installer, Version 11.2.0.1.0 Production
Copyright (C) 1999, 2009, Oracle. All rights reserved.
Performing tests to see whether nodes node2,node3 are available
……………………………………………………… 100% Done.
—————————————————————————–
Cluster Node Addition Summary
Global Settings
Source: /oracle/app/product/11.2.0/grid
New Nodes
Space Requirements
New Nodes
node3
/oracle: Required 4.30GB : Available 17.29GB
Installed Products
Product Names
Oracle Grid Infrastructure 11.2.0.1.0
Sun JDK 1.5.0.17.0
Installer SDK Component 11.2.0.1.0
Oracle One-Off Patch Installer 11.2.0.0.2
Oracle Universal Installer 11.2.0.1.0
Oracle Configuration Manager Deconfiguration 10.3.1.0.0
Enterprise Manager Common Core Files 10.2.0.4.2
Oracle DBCA Deconfiguration 11.2.0.1.0
Oracle RAC Deconfiguration 11.2.0.1.0
Oracle Quality of Service Management (Server) 11.2.0.1.0
Installation Plugin Files 11.2.0.1.0
Universal Storage Manager Files 11.2.0.1.0
Oracle Text Required Support Files 11.2.0.1.0
Automatic Storage Management Assistant 11.2.0.1.0
Oracle Database 11g Multimedia Files 11.2.0.1.0
Oracle Multimedia Java Advanced Imaging 11.2.0.1.0
Oracle Globalization Support 11.2.0.1.0
Oracle Multimedia Locator RDBMS Files 11.2.0.1.0
Oracle Core Required Support Files 11.2.0.1.0
Bali Share 1.1.18.0.0
Oracle Database Deconfiguration 11.2.0.1.0
Oracle Quality of Service Management (Client) 11.2.0.1.0
Expat libraries 2.0.1.0.1
Oracle Containers for Java 11.2.0.1.0
Perl Modules 5.10.0.0.1
Secure Socket Layer 11.2.0.1.0
Oracle JDBC/OCI Instant Client 11.2.0.1.0
Oracle Multimedia Client Option 11.2.0.1.0
闪念贝壳
闪念贝壳是一款AI 驱动的智能语音笔记，随时随地用语音记录你的每一个想法。
218 查看详情
LDAP Required Support Files 11.2.0.1.0
Character Set Migration Utility 11.2.0.1.0
Perl Interpreter 5.10.0.0.1
PL/SQL Embedded Gateway 11.2.0.1.0
OLAP SQL Scripts 11.2.0.1.0
Database SQL Scripts 11.2.0.1.0
Oracle Extended Windowing Toolkit 3.4.47.0.0
SSL Required Support Files for InstantClient 11.2.0.1.0
SQL*Plus Files for Instant Client 11.2.0.1.0
Oracle Net Required Support Files 11.2.0.1.0
Oracle Database User Interface 2.2.13.0.0
RDBMS Required Support Files for Instant Client 11.2.0.1.0
Enterprise Manager Minimal Integration 11.2.0.1.0
XML Parser for Java 11.2.0.1.0
Oracle Security Developer Tools 11.2.0.1.0
Oracle Wallet Manager 11.2.0.1.0
Enterprise Manager plugin Common Files 11.2.0.1.0
Platform Required Support Files 11.2.0.1.0
Oracle JFC Extended Windowing Toolkit 4.2.36.0.0
RDBMS Required Support Files 11.2.0.1.0
Oracle Ice Browser 5.2.3.6.0
Oracle Help For Java 4.2.9.0.0
Enterprise Manager Common Files 10.2.0.4.2
Deinstallation Tool 11.2.0.1.0
Oracle Java Client 11.2.0.1.0
Cluster Verification Utility Files 11.2.0.1.0
Oracle Notification Service (eONS) 11.2.0.1.0
Oracle LDAP administration 11.2.0.1.0
Cluster Verification Utility Common Files 11.2.0.1.0
Oracle Clusterware RDBMS Files 11.2.0.1.0
Oracle Locale Builder 11.2.0.1.0
Oracle Globalization Support 11.2.0.1.0
Buildtools Common Files 11.2.0.1.0
Oracle RAC Required Support Files-HAS 11.2.0.1.0
SQL*Plus Required Support Files 11.2.0.1.0
XDK Required Support Files 11.2.0.1.0
Agent Required Support Files 10.2.0.4.2
Parser Generator Required Support Files 11.2.0.1.0
Precompiler Required Support Files 11.2.0.1.0
Installation Common Files 11.2.0.1.0
Required Support Files 11.2.0.1.0
Oracle JDBC/THIN Interfaces 11.2.0.1.0
Oracle Multimedia Locator 11.2.0.1.0
Oracle Multimedia 11.2.0.1.0
HAS Common Files 11.2.0.1.0
Assistant Common Files 11.2.0.1.0
PL/SQL 11.2.0.1.0
HAS Files for DB 11.2.0.1.0
Oracle Recovery Manager 11.2.0.1.0
Oracle Database Utilities 11.2.0.1.0
Oracle Notification Service 11.2.0.0.0
SQL*Plus 11.2.0.1.0
Oracle Netca Client 11.2.0.1.0
Oracle Net 11.2.0.1.0
Oracle JVM 11.2.0.1.0
Oracle Internet Directory Client 11.2.0.1.0
Oracle Net Listener 11.2.0.1.0
Cluster Ready Services Files 11.2.0.1.0
Oracle Database 11g 11.2.0.1.0
—————————————————————————–
Instantiating scripts for add node (Monday, July 30, 2012 3:47:59 PM CST)
