本教程将指导您如何利用css grid高效创建灵活且响应式的网页布局，特别是实现文本、图片和按钮的并排显示。我们将通过优化html结构、应用css grid属性，并结合响应式设计最佳实践，解决前端开发中常见的布局与适配问题，最终构建出在不同屏幕尺寸下均能良好呈现的专业级页面。
在现代网页设计中，创建既美观又能在各种设备上良好运行的响应式布局是一项核心技能。对于初学者而言，实现复杂的图文并排布局并确保其在不同屏幕尺寸下自适应，常常会遇到挑战。传统的浮动（float）或定位（position）方法虽然可以实现部分效果，但在维护性和灵活性方面往往不如现代CSS布局模块。CSS Grid（网格布局）提供了一种强大且直观的二维布局解决方案，能够轻松应对这类需求。
理解CSS Grid布局基础
CSS Grid是一种用于网页布局的强大工具，它允许开发者将页面内容划分为行和列，形成一个网格，然后将元素放置到这些网格单元中。其核心概念包括：
网格容器（Grid Container）：应用display: grid的父元素。网格项（Grid Items）：网格容器的直接子元素。网格线（Grid Lines）：构成网格的水平和垂直线。网格轨道（Grid Tracks）：网格线之间的空间，可以是行或列。
通过定义网格容器的属性，我们可以精确控制网格项的排列和尺寸，从而实现复杂的响应式布局。
优化HTML结构以适应Grid布局
在应用CSS Grid之前，首先需要对HTML结构进行适当的调整，以更好地配合网格布局的需求。对于需要将文本、图片和按钮并排显示的情况，一个常见的做法是将相关联的元素进行分组。
立即学习“前端免费学习笔记（深入）”；
考虑以下原始HTML结构：
We found trip that suits you
Kieve Summer Camp
Nobleboro, USA
Located on the shores of Lake Damariscotta in Maine, Kieve has been building boys' character and teaching them wilderness skills since 1926. With a heavy focus on excursions—only half the campers are usually on-site, with the other half exploring during the regular camping trips and half-day adventures—activities also include an extensive ropes course, lacrosse, baseball, woodworking, riflery, fishing, swimming, paddle boarding, windsurfing, sailing, tennis, soccer, and photography. A more traditional camp where each boy has a duty, plus takes part in daily activities such as a flag raising and evening prayer, campers are encouraged to try new activities and widen their comfort zones. A sister camp around the lake—Wavus Camp for Girls—operates under a similar philosophy, teaching bravery, resilience, and a reverence for nature.
@@##@@
为了实现文本在左侧，图片和按钮在右侧的布局，我们需要将图片和两个按钮封装在一个新的容器中。同时，为了更好地控制页面的整体宽度和居中，建议在body内部添加一个全局的wrapper容器。
优化后的HTML结构示例：
We found trip that suits you
Kieve Summer Camp
Nobleboro, USA
Located on the shores of Lake Damariscotta in Maine, Kieve has been building boys' character and teaching them wilderness skills since 1926. With a heavy focus on excursions—only half the campers are usually on-site, with the other half exploring during the regular camping trips and half-day adventures—activities also include an extensive ropes course, lacrosse, baseball, woodworking, riflery, fishing, swimming, paddle boarding, windsurfing, sailing, tennis, soccer, and photography. A more traditional camp where each boy has a duty, plus takes part in daily activities such as a flag raising and evening prayer, campers are encouraged to try new activities and widen their comfort zones. A sister camp around the lake—Wavus Camp for Girls—operates under a similar philosophy, teaching bravery, resilience, and a reverence for nature.
@@##@@
这里我们将图片和按钮进一步嵌套在right-col中，并为按钮创建了一个buttons-group容器，这为后续的布局和样式控制提供了更大的灵活性。
应用CSS Grid实现布局
现在，我们可以利用CSS Grid来定义.content区域的布局。
CSS样式示例：
body { margin: 0; background-color: #353535; font-family: 'Inter', serif; /* 统一字体 */ color: white; /* 统一文本颜色 */}.wrapper { max-width: 1200px; /* 限制页面最大宽度 */ margin: 0 auto; /* 页面居中 */ padding: 20px; /* 内边距 */}.header { text-align: center; font-size: 20px; font-weight: bold; width: 100%; /* 在wrapper内占满宽度 */ height: 150px; background-color: #3C6E71; border-radius: 25px; display: flex; /* 使用Flexbox居中h1 */ flex-direction: column; justify-content: center; align-items: center; margin-bottom: 20px; /* 与下方内容保持距离 */}.header h1 { margin: 3px 0; /* 调整h1的上下边距 */}.content { display: grid; /* 启用CSS Grid布局 */ grid-template-columns: repeat(2, 1fr); /* 定义两列，每列占据可用空间的1份 */ gap: 2em; /* 列间距 */ padding: 10px; background-color: #353535; /* 保持背景色一致 */ align-items: start; /* 网格项顶部对齐 */}.content p { margin: 0; /* 移除默认边距 */ line-height: 1.6; /* 增加行高提高可读性 */}.right-col { display: flex; /* 使用Flexbox布局图片和按钮组 */ flex-direction: column; /* 垂直堆叠 */ gap: 1em; /* 元素间距 */ align-items: center; /* 水平居中 */}.content img { max-width: 100%; /* 图片最大宽度为其父容器的100% */ height: auto; /* 高度自动调整以保持图片比例 */ object-fit: cover; border: 3px solid white; border-radius: 8px; /* 添加圆角 */}.buttons-group { display: flex; /* 按钮组内部使用Flexbox */ gap: 10px; /* 按钮间距 */ margin-top: 10px; /* 与图片保持距离 */}.button { background-color: #D9D9D9; border: none; color: #D00000; padding: 15px 32px; text-align: center; text-decoration: none; display: inline-block; font-size: 13px; cursor: pointer; font-family:'Trebuchet MS', 'Lucida Sans Unicode', 'Lucida Grande', 'Lucida Sans', Arial, sans-serif; border-radius: 5px; /* 添加圆角 */ transition: background-color 0.3s ease; /* 添加过渡效果 */}.button:hover { background-color: #c0c0c0; /* 悬停效果 */}
关键CSS Grid属性解释：
display: grid;：将.content元素转换为一个网格容器。grid-template-columns: repeat(2, 1fr);：定义了两列。repeat(2, …)表示重复两次，1fr表示“一份可用空间”。这意味着两列将平分.content容器的宽度。使用1fr比固定的50%在处理gap时更灵活。gap: 2em;：设置网格行和列之间的间距。align-items: start;：将网格项在其网格区域内沿垂直方向的起始位置对齐。
增强整体响应性
为了确保页面在小屏幕设备上也能有良好的用户体验，我们需要引入媒体查询（Media Queries）来调整布局。
添加媒体查询：
/* 针对小屏幕设备（例如，宽度小于768px） */@media (max-width: 768px) { .content { grid-template-columns: 1fr; /* 在小屏幕上变为单列布局 */ gap: 1em; /* 调整间距 */ } .right-col { align-items: stretch; /* 填充可用宽度 */ } .buttons-group { flex-direction: column; /* 按钮垂直堆叠 */ width: 100%; /* 按钮组宽度占满 */ } .button { width: 100%; /* 按钮宽度占满 */ box-sizing: border-box; /* 包含padding和border在宽度内 */ } .header { height: auto; /* 头部高度自适应 */ padding: 15px; }}
在上述媒体查询中：
当屏幕宽度小于或等于768px时，.content的布局会从两列变为单列（grid-template-columns: 1fr;），使内容垂直堆叠，更适合移动设备阅读。right-col和buttons-group的Flexbox布局也进行了调整，以确保图片和按钮能够更好地适应单列布局。
完整代码示例
将以上HTML和CSS代码整合，即可得到一个功能完善的响应式图文布局页面。
HTML (index.html):
响应式图文布局教程 We found trip that suits you
Kieve Summer Camp
Nobleboro, USA
Located on the shores of Lake Damariscotta in Maine, Kieve has been building boys' character and teaching them wilderness skills since 1926. With a heavy focus on excursions—only half the campers are usually on-site, with the other half exploring during the regular camping trips and half-day adventures—activities also include an extensive ropes course, lacrosse, baseball, woodworking, riflery, fishing, swimming, paddle boarding, windsurfing, sailing, tennis, soccer, and photography. A more traditional camp where each boy has a duty, plus takes part in daily activities such as a flag raising and evening prayer, campers are encouraged to try new activities and widen their comfort zones. A sister camp around the lake—Wavus Camp for Girls—operates under a similar philosophy, teaching bravery, resilience, and a reverence for nature.
@@##@@
CSS (index.css):
body { margin: 0; background-color: #353535; font-family: 'Inter', serif; color: white;}.wrapper { max-width: 1200px; margin: 0 auto; padding: 20px;}.header { text-align: center; font-size: 20px; font-weight: bold; width: 100%; height: 150px; background-color: #3C6E71; border-radius: 25px; display: flex; flex-direction: column; justify-content: center; align-items: center; margin-bottom: 20px;}.header h1 { margin: 3px 0;}.content { display: grid; grid-template-columns: repeat(2, 1fr); gap: 2em; padding: 10px; background-color: #353535; align-items: start;}.content p { margin: 0; line-height: 1.6;}.right-col { display: flex; flex-direction: column; gap: 1em; align-items: center;}.content img { max-width: 100%; height: auto; object-fit: cover; border: 3px solid white; border-radius: 8px;}.buttons-group { display: flex; gap: 10px; margin-top: 10px;}.button { background-color: #D9D9D9; border: none; color: #D00000; padding: 15px 32px; text-align: center; text-decoration: none; display: inline-block; font-size: 13px; cursor: pointer; font-family:'Trebuchet MS', 'Lucida Sans Unicode', 'Lucida Grande', 'Lucida Sans', Arial, sans-serif; border-radius: 5px; transition: background-color 0.3s ease;}.button:hover { background-color: #c0c0c0;}/* 媒体查询 */@media (max-width: 768px) { .content { grid-template-columns:
