点云生成：基于Paddle2.0实现WGAN-GP在点云上的一些尝试

本文尝试在点云上应用WGAN-GP，判别器借鉴PointNet结构，生成器为自定义搭建。使用ModelNet40数据集，取1024个点训练。定义了FeatureNet、UFeatureNet等网络，通过Adam优化器训练，每2轮可视化生成结果，20轮保存模型，目前可运行但效果待提升。

☞☞☞AI 智能聊天, 问答助手, AI 智能搜索, 免费无限量使用 DeepSeek R1 模型☜☜☜

点云生成：点云上使用WGAN-GP的一次尝试

项目说明

①说明

    尝试了下在点云上使用了WGAN-GP。

    1、判别器借鉴了PointNet结构。

    2、生成器是随手乱搭的哈哈。

    3、能跑通，效果有待改进。

②数据集

    ModelNet总共有662中目标分类，127915个CAD，以及十类标记过方向朝向的数据。其中包含了三个子集：

    1、ModelNet10：十个标记朝向的子集数据；

    2、ModelNet40：40个类别的三维模型；

    3、Aligned40：40类标记的三维模型。

    这里使用了ModelNet40，并且归一化了，文件中的数据的意义：

    1、横轴有六个数字，分别代表：x, y, z, r, g, b；

    2、纵轴为点，每份数据一共有10000个点，项目中每份数据抽取其中1024个点进行训练。

In [ ]

!unzip data/data50045/modelnet40_normal_resampled.zip!mv modelnet40_normal_resampled dataset

项目主体

①导入需要的库

In [ ]

import osimport numpy as npimport randomfrom mpl_toolkits import mplot3dimport matplotlib.pyplot as pltimport paddleimport paddle.nn.functional as Ffrom paddle.nn import Conv2D, Conv2DTranspose, MaxPool2D, Linear, BatchNorm, Dropout, ReLU, Tanh, LeakyReLU, Sequential

②数据处理

1、类别

In [ ]

category = {    'airplane': 0,}

2、生成训练和测试样本的list

In [ ]

def getDatalist(file_path='./dataset/modelnet40_shape_names.txt'):    f = open(file_path, 'r')    f_train = open('./dataset/train.txt', 'w')    f_test = open('./dataset/test.txt', 'w')    for category in f:        if category.split('n')[0] == 'airplane':            dict_path = os.path.join('./dataset/', category.split('n')[0])            data_dict = os.listdir(dict_path)            count = 0            for data_path in data_dict:                if count % 61 != 0:                    f_train.write(os.path.join(dict_path, data_path) + ' ' + category)                else:                    f_test.write(os.path.join(dict_path, data_path) + ' ' + category)                count += 1    f_train.close()    f_test.close()    f.close()if __name__ == '__main__':    getDatalist()

3、数据读取

In [ ]

def pointDataLoader(file_path='./dataset/train.txt', mode='train'):    BATCHSIZE = 8    MAX_POINT = 250    datas = []    labels = []    f = open(file_path)    for data_list in f:        point_data = []        data_path = data_list.split(' ')[0]        data_file = open(data_path)        point_num = 0        for points in data_file:            if point_num == MAX_POINT:                break            point_data.append([                float(points.split(',')[0]),                float(points.split(',')[1]),                float(points.split(',')[2])            ])            point_num += 1        datas.append(point_data)        labels.append(category[data_list.split(' ')[1].split('n')[0]])    f.close()    datas = np.array(datas)    labels = np.array(labels)    index_list = list(range(len(datas)))    def pointDataGenerator():        if mode == 'train':            random.shuffle(index_list)        datas_list = []        labels_list = []        for i in index_list:            data = np.reshape(datas[i], [1, 250, 3]).astype('float32')            label = np.reshape(labels[i], [1]).astype('int64')            datas_list.append(data)             labels_list.append(label)            if len(datas_list) == BATCHSIZE:                yield np.array(datas_list), np.array(labels_list)                datas_list = []                labels_list = []        if len(datas_list) > 0:            yield np.array(datas_list), np.array(labels_list)    return pointDataGenerator

③定义网络

1、定义网络

1.1、提取特征网络

In [ ]

class FeatureNet(paddle.nn.Layer):    def __init__(self, name_scope='FeatureNet_', num_point=256):        super(FeatureNet, self).__init__()        self.input_transform_net = Sequential(            Conv2D(1, 64, (1, 3)),            BatchNorm(64),            ReLU(),            Conv2D(64, 256, (1, 1)),            BatchNorm(256),            ReLU(),            MaxPool2D((num_point, 1))        )        self.input_fc = Sequential(            Linear(256, 64),            ReLU(),            Linear(64, 9,                 weight_attr=paddle.framework.ParamAttr(initializer=paddle.nn.initializer.Assign(paddle.zeros((64, 9)))),                bias_attr=paddle.framework.ParamAttr(initializer=paddle.nn.initializer.Assign(paddle.reshape(paddle.eye(3), [-1])))            )        )        self.mlp_1 = Sequential(            Conv2D(1, 64, (1, 3)),            BatchNorm(64),            ReLU(),            Conv2D(64, 16,(1, 1)),            BatchNorm(16),            ReLU(),        )        self.feature_transform_net = Sequential(            Conv2D(16, 16, (1, 1)),            BatchNorm(16),            ReLU(),            MaxPool2D((num_point, 1))        )        self.feature_fc = Sequential(            Linear(16, 8),            ReLU(),            Linear(8, 16*16)        )        self.mlp_2 = Sequential(            Conv2D(16, 8, (1, 1)),            BatchNorm(8),            ReLU()        )        def forward(self, inputs):        """        input: [batchsize, 1, 250, 3]        output: [batchsize, 250, 1]        """        batchsize = inputs.shape[0]        t_net = self.input_transform_net(inputs)        t_net = paddle.squeeze(t_net)        t_net = self.input_fc(t_net)        t_net = paddle.reshape(t_net, [batchsize, 3, 3])        x = paddle.squeeze(inputs)        x = paddle.matmul(x, t_net)        x = paddle.unsqueeze(x, axis=1)        x = self.mlp_1(x)        t_net = self.feature_transform_net(x)        t_net = paddle.squeeze(t_net)        t_net = self.feature_fc(t_net)        t_net = paddle.reshape(t_net, [batchsize, 16, 16])        x = paddle.squeeze(x)        x = paddle.transpose(x, (0, 2, 1))        x = paddle.matmul(x, t_net)        x = paddle.transpose(x, (0, 2, 1))        x = paddle.unsqueeze(x, axis=-1)        x = self.mlp_2(x)        x = paddle.max(x, axis=2)        return x

1.2、生成点云网络

In [ ]

class UFeatureNet(paddle.nn.Layer):    def __init__(self, name_scope='UFeatureNet_', num_point=1024):        super(UFeatureNet, self).__init__()        self.stage_1 = Sequential(            Conv2DTranspose(1, 4, (1, 3)),            BatchNorm(4),            LeakyReLU(),            Conv2D(4, 16, (1, 1)),            BatchNorm(16),            LeakyReLU()        )        self.stage_2 = Sequential(            Conv2DTranspose(16, 32, (4, 4), (2, 1)),            BatchNorm(32),            LeakyReLU(),            Conv2D(32, 128, (1, 1)),            BatchNorm(128),            LeakyReLU()        )        self.stage_3 = Sequential(            Conv2DTranspose(128, 128, (4, 4), (2, 1)),            BatchNorm(128),            LeakyReLU(),            Conv2D(128, 64, (1, 3)),            BatchNorm(64),            LeakyReLU()        )        self.stage_4 = Sequential(            Conv2DTranspose(64, 32, (4, 1), (1, 1)),            BatchNorm(32),            LeakyReLU(),            Conv2D(32, 32, (1, 3)),            BatchNorm(32),            LeakyReLU()        )        self.stage_5 = Sequential(            Conv2DTranspose(32, 16, (2, 1), (1, 1)),            BatchNorm(16),            LeakyReLU(),            Conv2D(16, 1, (1, 3)),            Tanh()        )    def forward(self, inputs):        """        input: [batchsize, 1, 60, 1]        output: [batchsize, 1, 250, 3]        """        x = self.stage_1(inputs)        x = self.stage_2(x)        x = self.stage_3(x)        x = self.stage_4(x)        x = self.stage_5(x)        return x

1.3、D网络

In [ ]

class D(paddle.nn.Layer):    def __init__(self, name_scope='D_'):        super(D, self).__init__()        self.feature_net = FeatureNet()        self.fc = Sequential(            Linear(8, 8),            ReLU(),            Dropout(p=0.7),            Linear(8, 1)        )    def forward(self, inputs):        """        input: [batchsize, 1, 250, 3]        output: [batchsize, 1]        """        x = self.feature_net(inputs)        x = paddle.squeeze(x)        x = self.fc(x)        return x

1.4、G网络

In [ ]

class G(paddle.nn.Layer):    def __init__(self, name_scope='G_'):        super(G, self).__init__()        self.u_feature_net = UFeatureNet()    def forward(self, inputs):        """        input: [batchsize, 1, 60, 1]        output: [batchsize, 1, 250, 3]        """        x = self.u_feature_net(inputs)        return x

2、模型结构可视化

In [ ]

Discriminator = D()paddle.summary(Discriminator, (8, 1, 250, 3))

--------------------------------------------------------------------------- Layer (type)       Input Shape          Output Shape         Param #    ===========================================================================   Conv2D-1       [[8, 1, 250, 3]]     [8, 64, 250, 1]          256        BatchNorm-1    [[8, 64, 250, 1]]     [8, 64, 250, 1]          256          ReLU-1       [[8, 64, 250, 1]]     [8, 64, 250, 1]           0          Conv2D-2      [[8, 64, 250, 1]]     [8, 256, 250, 1]       16,640       BatchNorm-2    [[8, 256, 250, 1]]    [8, 256, 250, 1]        1,024         ReLU-2       [[8, 256, 250, 1]]    [8, 256, 250, 1]          0         MaxPool2D-1    [[8, 256, 250, 1]]     [8, 256, 1, 1]           0          Linear-1          [[8, 256]]            [8, 64]            16,448         ReLU-3           [[8, 64]]             [8, 64]               0          Linear-2          [[8, 64]]              [8, 9]              585         Conv2D-3       [[8, 1, 250, 3]]     [8, 64, 250, 1]          256        BatchNorm-3    [[8, 64, 250, 1]]     [8, 64, 250, 1]          256          ReLU-4       [[8, 64, 250, 1]]     [8, 64, 250, 1]           0          Conv2D-4      [[8, 64, 250, 1]]     [8, 16, 250, 1]         1,040       BatchNorm-4    [[8, 16, 250, 1]]     [8, 16, 250, 1]          64           ReLU-5       [[8, 16, 250, 1]]     [8, 16, 250, 1]           0          Conv2D-5      [[8, 16, 250, 1]]     [8, 16, 250, 1]          272        BatchNorm-5    [[8, 16, 250, 1]]     [8, 16, 250, 1]          64           ReLU-6       [[8, 16, 250, 1]]     [8, 16, 250, 1]           0         MaxPool2D-2    [[8, 16, 250, 1]]      [8, 16, 1, 1]            0          Linear-3          [[8, 16]]              [8, 8]              136          ReLU-7            [[8, 8]]              [8, 8]               0          Linear-4           [[8, 8]]             [8, 256]            2,304        Conv2D-6      [[8, 16, 250, 1]]      [8, 8, 250, 1]          136        BatchNorm-6     [[8, 8, 250, 1]]      [8, 8, 250, 1]          32           ReLU-8        [[8, 8, 250, 1]]      [8, 8, 250, 1]           0        FeatureNet-1     [[8, 1, 250, 3]]        [8, 8, 1]              0          Linear-5           [[8, 8]]              [8, 8]              72           ReLU-9            [[8, 8]]              [8, 8]               0          Dropout-1          [[8, 8]]              [8, 8]               0          Linear-6           [[8, 8]]              [8, 1]               9       ===========================================================================Total params: 39,850Trainable params: 38,154Non-trainable params: 1,696---------------------------------------------------------------------------Input size (MB): 0.02Forward/backward pass size (MB): 19.45Params size (MB): 0.15Estimated Total Size (MB): 19.63---------------------------------------------------------------------------

{'total_params': 39850, 'trainable_params': 38154}

               In [ ]

Generator = G()paddle.summary(Generator, (8, 1, 60, 1))

-----------------------------------------------------------------------------  Layer (type)        Input Shape          Output Shape         Param #    =============================================================================Conv2DTranspose-1   [[8, 1, 60, 1]]       [8, 4, 60, 3]           16          BatchNorm-7      [[8, 4, 60, 3]]       [8, 4, 60, 3]           16          LeakyReLU-1      [[8, 4, 60, 3]]       [8, 4, 60, 3]            0           Conv2D-7        [[8, 4, 60, 3]]       [8, 16, 60, 3]          80          BatchNorm-8      [[8, 16, 60, 3]]      [8, 16, 60, 3]          64          LeakyReLU-2      [[8, 16, 60, 3]]      [8, 16, 60, 3]           0       Conv2DTranspose-2   [[8, 16, 60, 3]]     [8, 32, 122, 6]         8,224        BatchNorm-9     [[8, 32, 122, 6]]     [8, 32, 122, 6]          128         LeakyReLU-3     [[8, 32, 122, 6]]     [8, 32, 122, 6]           0           Conv2D-8       [[8, 32, 122, 6]]     [8, 128, 122, 6]        4,224       BatchNorm-10     [[8, 128, 122, 6]]    [8, 128, 122, 6]         512         LeakyReLU-4     [[8, 128, 122, 6]]    [8, 128, 122, 6]          0       Conv2DTranspose-3  [[8, 128, 122, 6]]    [8, 128, 246, 9]       262,272      BatchNorm-11     [[8, 128, 246, 9]]    [8, 128, 246, 9]         512         LeakyReLU-5     [[8, 128, 246, 9]]    [8, 128, 246, 9]          0           Conv2D-9       [[8, 128, 246, 9]]    [8, 64, 246, 7]        24,640       BatchNorm-12     [[8, 64, 246, 7]]     [8, 64, 246, 7]          256         LeakyReLU-6     [[8, 64, 246, 7]]     [8, 64, 246, 7]           0       Conv2DTranspose-4  [[8, 64, 246, 7]]     [8, 32, 249, 7]         8,224       BatchNorm-13     [[8, 32, 249, 7]]     [8, 32, 249, 7]          128         LeakyReLU-7     [[8, 32, 249, 7]]     [8, 32, 249, 7]           0           Conv2D-10      [[8, 32, 249, 7]]     [8, 32, 249, 5]         3,104       BatchNorm-14     [[8, 32, 249, 5]]     [8, 32, 249, 5]          128         LeakyReLU-8     [[8, 32, 249, 5]]     [8, 32, 249, 5]           0       Conv2DTranspose-5  [[8, 32, 249, 5]]     [8, 16, 250, 5]         1,040       BatchNorm-15     [[8, 16, 250, 5]]     [8, 16, 250, 5]          64          LeakyReLU-9     [[8, 16, 250, 5]]     [8, 16, 250, 5]           0           Conv2D-11      [[8, 16, 250, 5]]      [8, 1, 250, 3]          49            Tanh-1         [[8, 1, 250, 3]]      [8, 1, 250, 3]           0         UFeatureNet-1     [[8, 1, 60, 1]]       [8, 1, 250, 3]           0       =============================================================================Total params: 313,681Trainable params: 311,873Non-trainable params: 1,808-----------------------------------------------------------------------------Input size (MB): 0.00Forward/backward pass size (MB): 115.48Params size (MB): 1.20Estimated Total Size (MB): 116.68-----------------------------------------------------------------------------

{'total_params': 313681, 'trainable_params': 311873}

               In [ ]

def gradient_penalty(discriminator, real, fake, batchsize):    t = paddle.uniform((batchsize,1,1,1))    t = paddle.expand_as(t, real)    inter = t * real +  (1-t) * fake    inter.stop_gradient = False    inter_ = discriminator(inter)    grads = paddle.grad(inter_, [inter])[0]    grads = paddle.reshape(grads, [batchsize, grads.shape[1], grads.shape[2], grads.shape[3]])    epsilon = 1e-12    norm = paddle.sqrt(        paddle.mean(paddle.square(grads), axis=1) + epsilon    )    gp = paddle.mean((norm - 1)**2) * 10    return gp

⑤训练

1、Generator生成图片可视化

In [ ]

def draw(data):    zdata = []    xdata = []    ydata = []    for i in data[0][0]:        xdata.append(i[0])        ydata.append(i[1])        zdata.append(i[2])    xdata = np.array(xdata)    ydata = np.array(ydata)    zdata = np.array(zdata)    ax = plt.axes(projection='3d')    ax.scatter3D(xdata, ydata, zdata, c='r')    plt.savefig('fake.png')

2、训练

In [13]

def train():    train_loader = pointDataLoader(file_path='./dataset/train.txt', mode='train')    Discriminator = D()    Generator = G()    Discriminator.train()    Generator.train()    optim1 = paddle.optimizer.Adam(parameters=Discriminator.parameters(), weight_decay=0.001, learning_rate=1e-5)    optim2 = paddle.optimizer.Adam(parameters=Generator.parameters(), weight_decay=0.001, learning_rate=1e-5)    epoch_num = 2000    train_g = 2    for epoch in range(epoch_num):        for batch_id, data in enumerate(train_loader()):            real = paddle.to_tensor(data[0])            noise = paddle.uniform((real.shape[0], 1, 60, 1))            fake = Generator(noise)            fake_loss = paddle.mean(Discriminator(fake))            real_loss = -1*paddle.mean(Discriminator(real))            gp = gradient_penalty(Discriminator, real, fake, real.shape[0])            d_loss = fake_loss + real_loss + gp            d_loss.backward()            optim1.step()            optim1.clear_grad()            for _ in range(train_g):                noise = paddle.uniform((real.shape[0], 1, 60, 1))                fake = Generator(noise)                g_loss = -1*paddle.mean(Discriminator(fake))                g_loss.backward()                optim2.step()                optim2.clear_grad()            if batch_id % 32 == 0:                 print("epoch: {}, batch_id: {}, d_loss is: {}, g_loss is: {}".format(epoch, batch_id, d_loss.numpy(), g_loss.numpy()))                if epoch % 2 == 0:            noise = paddle.uniform((real.shape[0], 1, 60, 1))            fake = Generator(noise)            draw(fake.numpy())        if epoch % 20 == 0:            paddle.save(Discriminator.state_dict(), './model/D.pdparams')            paddle.save(optim1.state_dict(), './model/D.pdopt')            paddle.save(Generator.state_dict(), './model/G.pdparams')            paddle.save(optim2.state_dict(), './model/G.pdopt')if __name__ == '__main__':    train()
