我主要体验了下几个关于replication的工具。 其他的可以参见手册。
先说下我的环境：
MASTER: 192.168.1.131
SLAVE: 192.168.1.132, 192.168.1.133
三台DB都有对外的ALL权限用户。
各个配置文件如下，
[root@mysql56-master home]# cat /etc/my.cnf[mysqld]user = yttskip-name-resolveinnodb_buffer_pool_size = 128Mbasedir = /usr/local/mysqldatadir = /usr/local/mysql/dataport = 3306server_id = 131socket = /tmp/mysql.sockexplicit_defaults_for_timestamplog-bin=mysql56-master-binbinlog-ignore-db=mysqlgtid-mode=onenforce-gtid-consistencylog-slave-updatesbinlog-format=ROWsync-master-info=1report-host=192.168.1.131report-port=3306master_info_repository=tablerelay_log_info_repository=table
其他两台SERVER，除了SERVER-ID，香港服务器租用，都基本相同，我就不贴了。
1. MYSQLREPLICATE 搭建主从的脚本，这里我搭建了两台从机。
mysqlreplicate –master=root:root@192.168.1.131:3306 –slave=root:root@192.168.1.132:3306;…[root@mysql56-master home]# ./replicate_create# master on 192.168.1.131: … connected.# slave on 192.168.1.132: … connected.# Checking for binary logging on master…# Setting up replication…# …done.# master on 192.168.1.131: … connected.# slave on 192.168.1.133: … connected.# Checking for binary logging on master…# Setting up replication…# …done.
2. mysqlrplcheck 检查主从的运行情况。
天工
昆仑万维推出的通用AI智能体平台，原天工AI
212 查看详情
[root@mysql56-master home]# mysqlrplcheck –master=root:root@192.168.1.131:3306 –slave=root:root@192.168.1.132:3306 -s# master on 192.168.1.131: … connected.# slave on 192.168.1.132: … connected.Test DescriptionStatus—————————————————————————Checking for binary logging on master[pass]Are there binlog exceptions?[WARN]+———+——–+————+| server | do_db | ignore_db |+———+——–+————+| master || mysql|| slave || mysql|+———+——–+————+Replication user exists?[pass]Checking server_id values[pass]Checking server_uuid values[pass]Is slave connected to master?[pass]Check master information file[pass]Checking InnoDB compatibility[pass]Checking storage engines compatibility[pass]Checking lower_case_table_names settings[pass]Checking slave delay (seconds behind master)[pass]## Slave status:#Slave_IO_State : Waiting for master to send eventMaster_Host : 192.168.1.131Master_User : rplMaster_Port : 3306Connect_Retry : 60Master_Log_File : mysql56-master-bin.000002Read_Master_Log_Pos : 151Relay_Log_File : mysql56-slave-relay-bin.000003Relay_Log_Pos : 379Relay_Master_Log_File : mysql56-master-bin.000002Slave_IO_Running : YesSlave_SQL_Running : YesReplicate_Do_DB :Replicate_Ignore_DB : mysqlReplicate_Do_Table :Replicate_Ignore_Table :Replicate_Wild_Do_Table :Replicate_Wild_Ignore_Table :Last_Errno : 0Last_Error :Skip_Counter : 0Exec_Master_Log_Pos : 151Relay_Log_Space : 819Until_Condition : NoneUntil_Log_File :Until_Log_Pos : 0Master_SSL_Allowed : NoMaster_SSL_CA_File :Master_SSL_CA_Path :Master_SSL_Cert :Master_SSL_Cipher :Master_SSL_Key :Seconds_Behind_Master : 0 Master_SSL_Verify_Server_Cert : NoLast_IO_Errno : 0Last_IO_Error :Last_SQL_Errno : 0Last_SQL_Error :Replicate_Ignore_Server_Ids :Master_Server_Id : 131Master_UUID : 4d89ad1d-bc12-11e2-87e9-080027338857Master_Info_File : mysql.slave_master_infoSQL_Delay : 0SQL_Remaining_Delay : NoneSlave_SQL_Running_State : Slave has read all relay log; waiting for the slave I/O thread to update itMaster_Retry_Count : 86400Master_Bind :Last_IO_Error_Timestamp :Last_SQL_Error_Timestamp :Master_SSL_Crl :Master_SSL_Crlpath :Retrieved_Gtid_Set :Executed_Gtid_Set :Auto_Position : 1# …done.
3. mysqlrplshow. 显示主从的架构。
[root@mysql56-master home]# mysqlrplshow –master=root:root@192.168.1.131:3306 –discover-slaves-login=root:root -v# master on 192.168.1.131: … connected.# Finding slaves for master: 192.168.1.131:3306# Replication Topology Graph192.168.1.131:3306 (MASTER)|+— 192.168.1.132:3306 [IO running: Yes] – (SLAVE)|+— 192.168.1.133:3306 [IO running: Yes] – (SLAVE)[root@mysql56-master home]#
4. mysqlfailover. 监视主从健康状态。
[root@mysql56-master home]# mysqlfailover –master=root:root@192.168.1.131:3306 –discover-slaves-login=root:root# Discovering slaves for master at 192.168.1.131:3306# Discovering slave at 192.168.1.132:3306# Found slave: 192.168.1.132:3306# Discovering slave at 192.168.1.133:3306# Found slave: 192.168.1.133:3306# Checking privileges.MySQL Replication Failover UtilityFailover Mode = autoNext Interval = Tue May 14 12:27:56 2013Master Information——————Binary Log FilePosition Binlog_Do_DB Binlog_Ignore_DB mysql56-master-bin.0 151mysqlGTID Executed SetNoneReplication Health Status+—————-+——-+———+——–+————+——————————————-+| host| port | role | state | gtid_mode | health|+—————-+——-+———+——–+————+——————————————-+| 192.168.1.131 | 3306 | MASTER | UP| ON| OK|| 192.168.1.132 | 3306 | SLAVE | UP| ON| OK|| 192.168.1.133 | 3306 | SLAVE | UP| ON| Binary log and Relay log filters differ. |+—————-+——-+———+——–+————+——————————————-+Q-quit R-refresh H-health G-GTID Lists U-UUIDs[root@mysql56-master home]#
5. mysqlrpladmin. 对主从进行管理。
