mysql explain type连接类型示例

对于MySQL执行计划的获取，我们可以通过explain方式来查看，explain方式看似简单，实际上包含的内容很多，尤其是输出结果中的type类型列。理解这些不同的类型，对于我们SQL优化举足轻重，本文仅描述explian输出结果中的type列，同时给出其演示。有关explian输出的全描述，可以参考：MySQL EXPLAIN SQL 输出信息描述

一、EXPLAIN 语句中type列的值

type：    连接类型    system          表只有一行    const           表最多只有一行匹配，通用用于主键或者唯一索引比较时    eq_ref          每次与之前的表合并行都只在该表读取一行，这是除了system，const之外最好的一种，                    特点是使用=，而且索引的所有部分都参与join且索引是主键或非空唯一键的索引    ref             如果每次只匹配少数行，那就是比较好的一种，使用=或，可以是左覆盖索引或非主键或非唯一键    fulltext        全文搜索    ref_or_null     与ref类似，但包括NULL    index_merge     表示出现了索引合并优化(包括交集，并集以及交集之间的并集)，但不包括跨表和全文索引。                    这个比较复杂，目前的理解是合并单表的范围索引扫描（如果成本估算比普通的range要更优的话）    unique_subquery 在in子查询中，就是value in (select...)把形如“select unique_key_column”的子查询替换。                    PS：所以不一定in子句中使用子查询就是低效的！    index_subquery  同上，但把形如”select non_unique_key_column“的子查询替换    range           常数值的范围    index           a.当查询是索引覆盖的，即所有数据均可从索引树获取的时候（Extra中有Using Index）；                    b.以索引顺序从索引中查找数据行的全表扫描（无 Using Index）；                    c.如果Extra中Using Index与Using Where同时出现的话，则是利用索引查找键值的意思；                    d.如单独出现，则是用读索引来代替读行，但不用于查找    all             全表扫描

二、连接类型部分示例

1、all-- 环境描述(root@localhost) [sakila]> show variables like 'version';+---------------+--------+| Variable_name | Value  |+---------------+--------+| version       | 5.6.26 |+---------------+--------+MySQL采取全表遍历的方式来返回数据行，等同于Oracle的full table scan(root@localhost) [sakila]> explain select count(description) from film;+----+-------------+-------+------+---------------+------+---------+------+------+-------+| id | select_type | table | type | possible_keys | key  | key_len | ref  | rows | Extra |+----+-------------+-------+------+---------------+------+---------+------+------+-------+|  1 | SIMPLE      | film  | ALL  | NULL          | NULL | NULL    | NULL | 1000 | NULL  |+----+-------------+-------+------+---------------+------+---------+------+------+-------+2、indexMySQL采取索引全扫描的方式来返回数据行，等同于Oracle的full index scan(root@localhost) [sakila]> explain select title from film \G*************************** 1. row ***************************           id: 1  select_type: SIMPLE        table: film         type: indexpossible_keys: NULL          key: idx_title                key_len: 767                    ref: NULL                   rows: 1000                  Extra: Using index1 row in set (0.00 sec)3、  range索引范围扫描，对索引的扫描开始于某一点，返回匹配值域的行，常见于between、等的查询等同于Oracle的index range scan(root@localhost) [sakila]> explain select * from payment where customer_id>300 and customer_id explain select * from payment where customer_id in (200,300,400)\G*************************** 1. row ***************************           id: 1  select_type: SIMPLE          table: payment           type: rangepossible_keys: idx_fk_customer_id            key: idx_fk_customer_id        key_len: 2            ref: NULL           rows: 86          Extra: Using index condition1 row in set (0.00 sec)4、ref非唯一性索引扫描或者，返回匹配某个单独值的所有行。常见于使用非唯一索引即唯一索引的非唯一前缀进行的查找(root@localhost) [sakila]> explain select * from payment where customer_id=305\G*************************** 1. row ***************************           id: 1  select_type: SIMPLE          table: payment           type: refpossible_keys: idx_fk_customer_id            key: idx_fk_customer_id        key_len: 2            ref: const           rows: 25          Extra: 1 row in set (0.00 sec)idx_fk_customer_id为表payment上的外键索引，且存在多个不不唯一的值，如下查询(root@localhost) [sakila]> select customer_id,count(*) from payment group by customer_id    -> limit 2;+-------------+----------+| customer_id | count(*) |+-------------+----------+|           1 |       32 ||           2 |       27 |+-------------+----------+-- 下面是非唯一前缀索引使用ref的示例(root@localhost) [sakila]> create index idx_fisrt_last_name on customer(first_name,last_name);Query OK, 599 rows affected (0.09 sec)Records: 599  Duplicates: 0  Warnings: 0(root@localhost) [sakila]> select first_name,count(*) from customer group by first_name     -> having count(*)>1 limit 2;+------------+----------+| first_name | count(*) |+------------+----------+| JAMIE      |        2 || JESSIE     |        2 |+------------+----------+2 rows in set (0.00 sec)(root@localhost) [sakila]> explain select first_name from customer where first_name='JESSIE'\G*************************** 1. row ***************************           id: 1  select_type: SIMPLE        table: customer         type: refpossible_keys: idx_fisrt_last_name          key: idx_fisrt_last_name      key_len: 137          ref: const         rows: 2        Extra: Using where; Using index1 row in set (0.00 sec)(root@localhost) [sakila]> alter table customer drop index idx_fisrt_last_name;Query OK, 599 rows affected (0.03 sec)Records: 599  Duplicates: 0  Warnings: 0--下面演示出现在join是ref的示例(root@localhost) [sakila]> explain select b.*,a.* from payment a inner join    -> customer b on a.customer_id=b.customer_id\G*************************** 1. row ***************************           id: 1  select_type: SIMPLE        table: b         type: ALLpossible_keys: PRIMARY          key: NULL      key_len: NULL                ref: NULL               rows: 599              Extra: NULL      *************************** 2. row ***************************                 id: 1        select_type: SIMPLE              table: a               type: refpossible_keys: idx_fk_customer_id                key: idx_fk_customer_id            key_len: 2                ref: sakila.b.customer_id               rows: 13              Extra: NULL2 rows in set (0.01 sec)5、eq_ref类似于ref，其差别在于使用的索引为唯一索引，对于每个索引键值，表中只有一条记录与之匹配。多见于主键扫描或者索引唯一扫描。(root@localhost) [sakila]> explain select * from film a join film_text b     -> on a.film_id=b.film_id;+----+-------------+-------+--------+---------------+---------+---------+------------------+------+-------------+| id | select_type | table | type   | possible_keys | key     | key_len | ref         | rows | Extra       |+----+-------------+-------+--------+---------------+---------+---------+------------------+------+-------------+|  1 | SIMPLE      | b     | ALL    | PRIMARY       | NULL    | NULL    | NULL    | 1000 | NULL    ||  1 | SIMPLE      | a     | eq_ref | PRIMARY       | PRIMARY | 2       | sakila.b.film_id |    1 | Using where |+----+-------------+-------+--------+---------------+---------+---------+------------------+------+-------------+(root@localhost) [sakila]> explain select title from film where film_id=5;+----+-------------+-------+-------+---------------+---------+---------+-------+------+-------+| id | select_type | table | type  | possible_keys | key     | key_len | ref   | rows | Extra |+----+-------------+-------+-------+---------------+---------+---------+-------+------+-------+|  1 | SIMPLE      | film  | const | PRIMAR   | PRIMARY | 2       | const |    1 | NULL  |+----+-------------+-------+-------+---------------+---------+---------+-------+------+-------+6、const、system：当MySQL对查询某部分进行优化，这个匹配的行的其他列值可以转换为一个常量来处理。如将主键或者唯一索引置于where列表中，MySQL就能将该查询转换为一个常量(root@localhost) [sakila]> create table t1(id int,ename varchar(20) unique);Query OK, 0 rows affected (0.05 sec)(root@localhost) [sakila]> insert into t1 values(1,'robin'),(2,'jack'),(3,'henry');Query OK, 3 rows affected (0.00 sec)Records: 3  Duplicates: 0  Warnings: 0(root@localhost) [sakila]> explain select * from (select * from t1 where ename='robin')x;+----+-------------+------------+--------+---------------+-------+---------+-------+------+-------+| id | select_type | table      | type   | possible_keys | key   | key_len | ref   | rows | Extra |+----+-------------+------------+--------+---------------+-------+---------+-------+------+-------+|  1 | PRIMARY     |  | system | NULL          | NULL  | NULL    | NULL  |    1 | NULL  ||  2 | DERIVED     | t1         | const  | ename         | ename | 23      | const |    1 | NULL  |+----+-------------+------------+--------+---------------+-------+---------+-------+------+-------+2 rows in set (0.00 sec)7、type=NULLMySQL不用访问表或者索引就可以直接得到结果(root@localhost) [sakila]> explain select sysdate();+----+-------------+-------+------+---------------+------+---------+------+------+----------------+| id | select_type | table | type | possible_keys | key  | key_len | ref  | rows | Extra          |+----+-------------+-------+------+---------------+------+---------+------+------+----------------+|  1 | SIMPLE      | NULL  | NULL | NULL          | NULL | NULL    | NULL | NULL | No tables used |+----+-------------+-------+------+---------------+------+---------+------+------+----------------+1 row in set (0.00 sec)

对于MySQL执行计划的获取，我们可以通过explain方式来查看，explain方式看似简单，实际上包含的内容很多，尤其是输出结果中的type类型列。理解这些不同的类型，对于我们SQL优化举足轻重，本文仅描述explian输出结果中的type列，同时给出其演示。有关explian输出的全描述，可以参考：MySQL EXPLAIN SQL 输出信息描述

一、EXPLAIN 语句中type列的值

type：    连接类型    system          表只有一行    const           表最多只有一行匹配，通用用于主键或者唯一索引比较时    eq_ref          每次与之前的表合并行都只在该表读取一行，这是除了system，const之外最好的一种，                    特点是使用=，而且索引的所有部分都参与join且索引是主键或非空唯一键的索引    ref             如果每次只匹配少数行，那就是比较好的一种，使用=或，可以是左覆盖索引或非主键或非唯一键    fulltext        全文搜索    ref_or_null     与ref类似，但包括NULL    index_merge     表示出现了索引合并优化(包括交集，并集以及交集之间的并集)，但不包括跨表和全文索引。                    这个比较复杂，目前的理解是合并单表的范围索引扫描（如果成本估算比普通的range要更优的话）    unique_subquery 在in子查询中，就是value in (select...)把形如“select unique_key_column”的子查询替换。                    PS：所以不一定in子句中使用子查询就是低效的！    index_subquery  同上，但把形如”select non_unique_key_column“的子查询替换    range           常数值的范围    index           a.当查询是索引覆盖的，即所有数据均可从索引树获取的时候（Extra中有Using Index）；                    b.以索引顺序从索引中查找数据行的全表扫描（无 Using Index）；                    c.如果Extra中Using Index与Using Where同时出现的话，则是利用索引查找键值的意思；                    d.如单独出现，则是用读索引来代替读行，但不用于查找    all             全表扫描

二、连接类型部分示例

1、all-- 环境描述(root@localhost) [sakila]> show variables like 'version';+---------------+--------+| Variable_name | Value  |+---------------+--------+| version       | 5.6.26 |+---------------+--------+MySQL采取全表遍历的方式来返回数据行，等同于Oracle的full table scan(root@localhost) [sakila]> explain select count(description) from film;+----+-------------+-------+------+---------------+------+---------+------+------+-------+| id | select_type | table | type | possible_keys | key  | key_len | ref  | rows | Extra |+----+-------------+-------+------+---------------+------+---------+------+------+-------+|  1 | SIMPLE      | film  | ALL  | NULL          | NULL | NULL    | NULL | 1000 | NULL  |+----+-------------+-------+------+---------------+------+---------+------+------+-------+2、indexMySQL采取索引全扫描的方式来返回数据行，等同于Oracle的full index scan(root@localhost) [sakila]> explain select title from film \G*************************** 1. row ***************************           id: 1  select_type: SIMPLE        table: film         type: indexpossible_keys: NULL          key: idx_title                key_len: 767                    ref: NULL                   rows: 1000                  Extra: Using index1 row in set (0.00 sec)3、  range索引范围扫描，对索引的扫描开始于某一点，返回匹配值域的行，常见于between、等的查询等同于Oracle的index range scan(root@localhost) [sakila]> explain select * from payment where customer_id>300 and customer_id explain select * from payment where customer_id in (200,300,400)\G*************************** 1. row ***************************           id: 1  select_type: SIMPLE          table: payment           type: rangepossible_keys: idx_fk_customer_id            key: idx_fk_customer_id        key_len: 2            ref: NULL           rows: 86          Extra: Using index condition1 row in set (0.00 sec)4、ref非唯一性索引扫描或者，返回匹配某个单独值的所有行。常见于使用非唯一索引即唯一索引的非唯一前缀进行的查找(root@localhost) [sakila]> explain select * from payment where customer_id=305\G*************************** 1. row ***************************           id: 1  select_type: SIMPLE          table: payment           type: refpossible_keys: idx_fk_customer_id            key: idx_fk_customer_id        key_len: 2            ref: const           rows: 25          Extra: 1 row in set (0.00 sec)idx_fk_customer_id为表payment上的外键索引，且存在多个不不唯一的值，如下查询(root@localhost) [sakila]> select customer_id,count(*) from payment group by customer_id    -> limit 2;+-------------+----------+| customer_id | count(*) |+-------------+----------+|           1 |       32 ||           2 |       27 |+-------------+----------+-- 下面是非唯一前缀索引使用ref的示例(root@localhost) [sakila]> create index idx_fisrt_last_name on customer(first_name,last_name);Query OK, 599 rows affected (0.09 sec)Records: 599  Duplicates: 0  Warnings: 0(root@localhost) [sakila]> select first_name,count(*) from customer group by first_name     -> having count(*)>1 limit 2;+------------+----------+| first_name | count(*) |+------------+----------+| JAMIE      |        2 || JESSIE     |        2 |+------------+----------+2 rows in set (0.00 sec)(root@localhost) [sakila]> explain select first_name from customer where first_name='JESSIE'\G*************************** 1. row ***************************           id: 1  select_type: SIMPLE        table: customer         type: refpossible_keys: idx_fisrt_last_name          key: idx_fisrt_last_name      key_len: 137          ref: const         rows: 2        Extra: Using where; Using index1 row in set (0.00 sec)(root@localhost) [sakila]> alter table customer drop index idx_fisrt_last_name;Query OK, 599 rows affected (0.03 sec)Records: 599  Duplicates: 0  Warnings: 0--下面演示出现在join是ref的示例(root@localhost) [sakila]> explain select b.*,a.* from payment a inner join    -> customer b on a.customer_id=b.customer_id\G*************************** 1. row ***************************           id: 1  select_type: SIMPLE        table: b         type: ALLpossible_keys: PRIMARY          key: NULL      key_len: NULL                ref: NULL               rows: 599              Extra: NULL      *************************** 2. row ***************************                 id: 1        select_type: SIMPLE              table: a               type: refpossible_keys: idx_fk_customer_id                key: idx_fk_customer_id            key_len: 2                ref: sakila.b.customer_id               rows: 13              Extra: NULL2 rows in set (0.01 sec)5、eq_ref类似于ref，其差别在于使用的索引为唯一索引，对于每个索引键值，表中只有一条记录与之匹配。多见于主键扫描或者索引唯一扫描。(root@localhost) [sakila]> explain select * from film a join film_text b     -> on a.film_id=b.film_id;+----+-------------+-------+--------+---------------+---------+---------+------------------+------+-------------+| id | select_type | table | type   | possible_keys | key     | key_len | ref              | rows | Extra       |+----+-------------+-------+--------+---------------+---------+---------+------------------+------+-------------+|  1 | SIMPLE      | b     | ALL    | PRIMARY       | NULL    | NULL    | NULL          | 1000 | NULL   ||  1 | SIMPLE      | a     | eq_ref | PRIMARY       | PRIMARY | 2       | sakila.b.film_id |    1 | Using where |+----+-------------+-------+--------+---------------+---------+---------+------------------+------+-------------+(root@localhost) [sakila]> explain select title from film where film_id=5;+----+-------------+-------+-------+---------------+---------+---------+-------+------+-------+| id | select_type | table | type  | possible_keys | key     | key_len | ref   | rows | Extra |+----+-------------+-------+-------+---------------+---------+---------+-------+------+-------+|  1 | SIMPLE      | film  | const | PRIMARY       | PRIMARY | 2       | const |    1 | NULL  |+----+-------------+-------+-------+---------------+---------+---------+-------+------+-------+6、const、system：当MySQL对查询某部分进行优化，这个匹配的行的其他列值可以转换为一个常量来处理。如将主键或者唯一索引置于where列表中，MySQL就能将该查询转换为一个常量(root@localhost) [sakila]> create table t1(id int,ename varchar(20) unique);Query OK, 0 rows affected (0.05 sec)(root@localhost) [sakila]> insert into t1 values(1,'robin'),(2,'jack'),(3,'henry');Query OK, 3 rows affected (0.00 sec)Records: 3  Duplicates: 0  Warnings: 0(root@localhost) [sakila]> explain select * from (select * from t1 where ename='robin')x;+----+-------------+------------+--------+---------------+-------+---------+-------+------+-------+| id | select_type | table      | type   | possible_keys | key   | key_len | ref   | rows | Extra |+----+-------------+------------+--------+---------------+-------+---------+-------+------+-------+|  1 | PRIMARY     |  | system | NULL          | NULL  | NULL    | NULL  |    1 | NULL  ||  2 | DERIVED     | t1         | const  | ename         | ename | 23      | const |    1 | NULL  |+----+-------------+------------+--------+---------------+-------+---------+-------+------+-------+2 rows in set (0.00 sec)7、type=NULLMySQL不用访问表或者索引就可以直接得到结果(root@localhost) [sakila]> explain select sysdate();+----+-------------+-------+------+---------------+------+---------+------+------+----------------+| id | select_type | table | type | possible_keys | key  | key_len | ref  | rows | Extra          |+----+-------------+-------+------+---------------+------+---------+------+------+----------------+|  1 | SIMPLE      | NULL  | NULL | NULL          | NULL | NULL    | NULL | NULL | No tables used |+----+-------------+-------+------+---------------+------+---------+------+------+----------------+1 row in set (0.00 sec)

以上就是mysql explain type连接类型示例的内容，更多相关内容请关注创想鸟（www.php.cn）！
